Characters:
1) Compact structure
2) Attractive design
3) High efficiency, steady performance
4) High flow, medium pressure
5) High concentricity of components
Performance Range
Inlet diameter：125～1600 mm
Outlet diameter：80～1400 mm
Capacity：≤ 20000 m3/h
Head：≤ 200 m
Working temperature：＜ 105 ℃
Solid particles：≤ 80mg/L
Permitted working pressure：≤ 2.5 MPa
Permitted testing pressure：≤ 3.75 Mpa
Application:
1) Waterworks
2) Circulation water for air-conditioning
3) Water supplying for industry and building
4) Irrigation and drainage pumping station
5) Power station
Material
Casing: Cast iron,ductile iron ,Carbon steel ,stainless steel
Impeller: Cast iron,ductile iron ,Carbon steel ,stainless steel,brozne
Shaft: carbon steel, stainless steel
Shaft sleeve: cast iron,carbon steel, stainless steel,bronze
wear ring: cast iron,carbon steel, stainless steel,bronze
Bearing:NTN,NSK,SKF
Gland packing: Ramie,graphit,asbestos,Polytetrafluoroethylene
Mechanical seal:FAG,Burgmann,crane
